Dogwalk Glass Fitting Dog Door - Clear – G-DDC
Product Description
Dogwalk G-DDC Glass Fitting Dog Door
The Dogwalk G-DDC Glass Fitting Dog Door is designed specifically for installation into suitable glass doors, windows and glazed panels, providing independent access for medium to larger dogs.
Suitable for glass from 3mm to 32mm thick, the G-DDC can be used in suitable single and double-glazed installations. It features a generous 270mm x 313mm flap opening, 4-way locking system and weather-resistant construction.
Important for your glazier: The Dogwalk G-DDC requires a 385mm diameter circular glass cut-out. Confirm the pet door model and fitting requirements before ordering replacement glass.
Dogwalk G-DDC Dimensions & Glass Cut-Out
- Model: G-DDC
- Glass Cut-Out: 385mm diameter circular hole
- Overall Size: 415mm wide x 430mm high
- Flap Opening: 270mm wide x 313mm high
- Glass Thickness: 3mm to 32mm
- Pet Size: Medium to semi-large dogs
- Maximum Pet Weight: approximately 25kg
- Locking: 4-way locking system
Dog Door Designed for Glass Installation
Unlike conventional dog doors intended primarily for timber or uPVC panels, the Dogwalk G-DDC is specifically designed for suitable glass installations.
Applications can include:
- Single-glazed panels
- Double-glazed doors
- Glazed entrance doors
- Patio door glass
- Suitable sliding glass doors
- Suitable glazed panels and windows
Important: Toughened glass cannot normally be cut after manufacture, and an existing sealed double-glazed unit cannot simply have a hole added. A replacement glass unit manufactured with the correct opening will normally be required.
385mm Circular Glass Cut-Out
The Dogwalk G-DDC requires a 385mm diameter circular hole in the glass.
This is particularly important when ordering replacement double glazing. Give your glazier the G-DDC model number and 385mm cut-out requirement before the new glass unit is manufactured.
Do not order replacement glass until the pet door and all required fitting dimensions have been confirmed.
Suitable for Dogs up to Approximately 25kg
The Dogwalk G-DDC is designed for medium to semi-large dogs weighing up to approximately 25kg.
Depending on the individual dog's dimensions, this may include breeds such as:
- Beagles
- Spaniels
- Border Collies
- Similar appropriately sized dogs
Always measure your individual dog before ordering. Weight and breed should only be used as a general guide when selecting a pet door.
270mm x 313mm Flap Opening
The G-DDC provides an approximately 270mm wide x 313mm high flap opening, giving appropriately sized medium and larger dogs comfortable access through the door.
Compare these dimensions with your dog's actual measurements before ordering rather than relying solely on weight or breed.
4-Way Locking Dog Door
The Dogwalk G-DDC features a 4-way locking system, allowing you to control how your dog uses the pet door.
- In & Out – free access in both directions
- In Only – allows your dog to enter
- Out Only – allows your dog to leave
- Fully Locked – prevents access in either direction
This provides straightforward access control without requiring an electronic locking system.
Weather-Resistant Construction
The G-DDC is manufactured from UV-stabilised plastic designed for regular outdoor use.
Its smooth, quiet-action flap provides comfortable everyday access while maintaining a neat appearance within the glass installation.
Key Features
- Dogwalk G-DDC Glass Fitting Dog Door
- Designed specifically for suitable glass installations
- 385mm diameter circular glass cut-out
- 270mm x 313mm flap opening
- Overall size approximately 415mm x 430mm
- Suitable for glass from 3mm to 32mm thick
- Suitable for medium to semi-large dogs
- Recommended for dogs up to approximately 25kg
- 4-way locking control
- In Only, Out Only, In & Out and Fully Locked settings
- UV-stabilised plastic construction
- Weather-resistant design
- Quiet-action pet flap
- Suitable for selected glazed doors and patio doors
- Professional glazing recommended
Fitting the Dogwalk G-DDC into Double Glazing
If the G-DDC is being installed into a modern double-glazed or toughened glass door, do not attempt to cut the existing glass.
A glazier will normally need to manufacture a new glass unit with the required 385mm diameter circular opening. The replacement unit can then be installed into the existing frame before the Dogwalk pet door is fitted.
Choose the pet door and confirm all required fitting dimensions before ordering the replacement glass.
Frequently Asked Questions
What size hole do I need for a Dogwalk G-DDC?
The Dogwalk G-DDC requires a 385mm diameter circular glass hole. Confirm this measurement and the G-DDC model with your glazier before the replacement glass is manufactured.
What is the Dogwalk G-DDC flap opening size?
The flap opening is approximately 270mm wide x 313mm high.
What is the overall size of the G-DDC?
The Dogwalk G-DDC measures approximately 415mm wide x 430mm high.
Can the Dogwalk G-DDC be fitted into double glazing?
Yes. It is designed for suitable glass installations including compatible double-glazed units. A new glass unit manufactured with the required 385mm circular opening will normally be required.
What thickness of glass can the G-DDC fit?
The Dogwalk G-DDC is suitable for glass from 3mm to 32mm thick.
What size dog can use the G-DDC?
The G-DDC is intended for medium to semi-large dogs weighing up to approximately 25kg. Always compare your dog's actual dimensions with the 270mm x 313mm flap opening before ordering.
Does the Dogwalk G-DDC lock?
Yes. It has a 4-way locking system providing In Only, Out Only, In & Out and Fully Locked settings.
Can the G-DDC be fitted into a sliding patio door?
It can be used in suitable glazed patio and sliding-door installations, subject to the construction and glass specification of the particular door.
Can my existing double-glazed glass be cut?
Normally no. Toughened glass cannot normally be cut after manufacture and an existing sealed double-glazed unit will generally need to be replaced with a new unit manufactured with the correct 385mm diameter opening.
Should I order the glass before buying the dog door?
No. Confirm the exact Dogwalk G-DDC model and its 385mm glass cut-out before the replacement glass unit is ordered.
